產(chǎn)品特點
軸徑 Axle | 代碼 Cod e nu mbe r | 墊片尺寸 Washer size | 安裝尺寸 Installation size | |||||
d+0.25 | D-0.25 | T-0.05 | M±0.125 | h+0.4 +0.1 | T±0.25 | D1+0.12 | ||
8 | WC10 | 10 | 20 | 1.5 | 15 | 1.5 | 1 | 20 |
10 | WC12 | 12 | 24 | 18 | 24 | |||
12 | WC14 | 14 | 26 | 20 | 2 | 26 | ||
14 | WC16 | 16 | 30 | 23 | 30 | |||
16 | WC18 | 18 | 32 | 25 | 32 | |||
18 | WC20 | 20 | 36 | 28 | 3 | 36 | ||
20 | WC22 | 22 | 38 | 30 | 38 | |||
22 | WC24 | 24 | 42 | 33 | 42 | |||
24 | WC26 | 26 | 44 | 35 | 44 | |||
26 | WC28 | 28 | 48 | 38 | 4 | 48 | ||
30 | WC32 | 32 | 54 | 43 | 54 | |||
36 | WC38 | 38 | 62 | 50 | ||||
40 | WC42 | 42 | 66 | 54 | 66 | |||
46 | WC48 | 48 | 74 | 61 | 1.5 | 74 | ||
50 | WC52 | 52 | 78 | 65 | 78 | |||
60 | WC62 | 62 | 90 | 76 | 90 | |||
